Fast Cooling Vacuum Oil Quench Furnace Simple Operation For Die Steel

Name: Fast Cooling Vacuum Oil Quench Furnace Simple Operation For Die Steel
Brand: EasyFashion Industry
Price: 1 USD

Brand Name : EasyFashion Industry

Model Number : EF-ZKQY-100

Certification : CE Certificate

Place of Origin : China

MOQ : 1 set

Supply Ability : 10 set per year

Delivery Time : 120 days

Packaging Details : Standard packed by wooden cases and container.

Effective heating zone (mm) : 1000*600*450

Loading capacity (kg/batch) : 300

Heating power (kW) : 100

Heating elements : Graphite and molybdenum

Contact Now

Vacuum Oil Quenching Furnace

I. Overview

It is mainly applied to quenching heat treatment of high-speed steel, die steel, titanium alloy, etc.. Various technology choices and processing application range are provided with full-automatic programmable controlling.

II. Technical specifications

Model	EF-ZKQY-100
Effective heating zone (mm)	1000600450
Max. temperature (°C)	1350
Furnace temperature homogeneity(°C)	±5
Ultimate vacuum degree	2*10^-1
Ultimate vacuum degree	6.7*10^-3
Pressure rising rate (Pa/h)	≤0.67
Gas cooling pressure (bar)	≤2
Heating power (kW)	100
Heating elements	Graphite and molybdenum
Note: The above is standard configuration which is adjustable based on customer requirements.

III. Features

1. Vacuum degree and air cooling pressure are allowed to be adjusted to fit specific materials.

2. Simple operation and flexible input ensure stable performance. Manual and automatic operation can be switched readily. Moreover, alarms will be triggered automatically on failures of the vacuum oil quench furnace.

3. Unique gas cooling system comes with built-in air channel for maximized cooling efficiency.

4. This vacuum oil quenching furnace is fitted with high efficiency external oil cooling circulation system for quench.

5. Oil tank has large capacity. Inside the tank, there are nozzles in various directions. As a result, there will be intense convection and turbulence during oil spraying, whereby catering to quench for large workpieces.

Product Tags:

high temperature vacuum furnace

high temperature sintering furnace

China Fast Cooling Vacuum Oil Quench Furnace Simple Operation For Die Steel wholesale

Fast Cooling Vacuum Oil Quench Furnace Simple Operation For Die Steel Images
