short sintering time Spark Plasma Sintering Furnace for nanophase materials

Brand Name : easyfashion

Model Number : EF-SPS10T

Certification : CE, CB

Place of Origin : Hunan, China (Mainland)

MOQ : 1 Set/Sets

Price : US $10,000 - 1,000,000 / Set

Payment Terms : L/C, D/A, D/P, Western Union

Supply Ability : 5 Set/Sets per Year

Delivery Time : 30-90days

Packaging Details : Standard export wooden cases

Usage : Process Testing Machine

Rated temperature : 2300℃

Powder : Electronic

Maximum pressure : 10-20T

Contact Now

Spark Plasma Sintering Furnace

Overview

The spark plasma sintering furnace (SPS) is one of the most advanced sintering furnace. With characteristics of fast sintering and high density of specimen, this furnace is mainly applied to sinter nanophase materials, functionally graded materials (FGM), nanoscale thermoelectric materials, rare earth permanent magnets, target materials, nonequilibrium materials and medical implants, etc..

short sintering time Spark Plasma Sintering Furnace for nanophase materials

Technical specifications

Model	Rated power	Output current	Input voltage		Max. working temperature	Max. pressure		Specimen size		Pressure head stroke	Ultimate Vacuum
EF-10T-5	50kW	0~5000A		0~10V	2300°C		10T		Ф 50	100mm	10Pa
EF-20T-10	100kW	0~10000A		0~10V	2300°C		20T		Ф 100	100mm	10^-3Pa

Features

1. High heating rate, short sintering time, high efficiency, energy saving and small occupied space.

2. Widely applications in the fields of metals, ceramics, nanometer materials, non-crystalline material, composite materials and functionally graded materials, etc..

3. Easy and safe operation under vacuum or protective atmosphere. It has alarms functions of power cut, water break, under-pressure, over-temperature and electrical interlock function. It also integrates vacuum, pressing and sintering as full automation control.

short sintering time Spark Plasma Sintering Furnace for nanophase materials
