90 X 120 Hot Zone Vacuum Heat Treatment Furnace Vacuum Hot Press Furnace

Name: 90 X 120 Hot Zone Vacuum Heat Treatment Furnace Vacuum Hot Press Furnace
Brand: EasyFashion
Price: 1 USD

Brand Name : EasyFashion

Certification : ISO9001:2008

Place of Origin : China

MOQ : 1 set

Price : To be discussed

Payment Terms : T/T, Western Union

Supply Ability : 2-10 sets per year

Delivery Time : 180 working days

Packaging Details : standard packing, wooden cases

Rated power : 25

Max. working temperature : 2000°C

Hot zone : 90x120

Ultimate vacuum : 5x10-3 Pa

Max. pressure : 10T

Contact Now

Vacuum Hot Press Furnace

Overview

The vacuum hot press furnace is batch type furnace and heating methods include graphite heating, molybdenum heating and medium frequency heating. This sintering furnace is well-suited for hot pressure sintering of hard alloy, functional ceramic and powder metallurgy in high temperature and high vacuum/protective gas. The output products are highly compacted to prevent deformation. The crystal grain of nanometer materials can be restrained to grow.

Technical specifications

Model	Rated power	Max. working temperature	Hot zone	Ultimate vacuum	Max. pressure	Stroke
EF-25-20Y	25kW	2000°C	90 ×120	5 ×10^-3 Pa	10T	100mm
EF-40-20Y	40kW	2000°C	160 ×160	5 ×10^-3 Pa	20T	100mm
EF-30-16Y	30kW	1600°C	150 ×200	6 ×10^-4 Pa	20T	150mm
EF-18-10Y	18kW	1000°C	200 ×200	5 ×10^-4 Pa	20T	150mm
EF-63-20Y	63kW	2000°C	250 ×250	5 ×10^-3 Pa	30T	100mm
EF-50-22Y	50kW	2200°C	150 ×180	5 ×10^-4 Pa	10T	100mm
EF-150-26Y	150kW	2600°C	300 ×300	10Pa	100T	150mm

Features

1. Double-layer water jacket cooled structure on furnace shell to improve cooling rate.

2. Suitable distribution of heating elements (graphite, molybdenum or induction heating) to improve heat uniformity.

3. Dedicated design on furnace structure to reduce evacuation time.

4. High automation and safe operation. The control system has the sound and light alarms and protection functions of abnormal phenomena such as water break, over-temperature, over-current and automatic switch failure of thermocouple.
